Description

Technical Product Overview:
The B-link Mini PC is a small form factor desktop computer equipped with an Intel Atom x5-Z8500 processor and integrated Intel HD Graphics. This device is pre-configured with Windows 10 and is designed for low-power operation (18W maximum). The hardware supports wireless and wired networking and features dual-display output capabilities via HDMI and VGA.

Key Technical Features:
-Processor Architecture: Utilizes the Intel Atom x5-Z8500 (2M Cache, 1.44GHz to 2.24GHz)
-Memory & Storage: Integrated 4GB RAM and 64GB of solid-state/flash storage for operating system and data tasks
-Connectivity Interface: Includes 4 x USB 3.0 ports, Gigabit Ethernet (1000M), and a TF card slot for external storage expansion
-Display Output: Dual video interfaces featuring 1 x HDMI and 1 x VGA ports
-Wireless Standards: Supports Dual-band Wi-Fi (802.11 b/g/n/ac) and Bluetooth 4.0
-Power Management: Powered by a 12V-1.5A (18W) adapter with a 100-240V AC input
-Physical Form Factor: Chassis dimensions are 120 x 120 x 22 mm with a device weight of 0.238 kg

Technical Specifications:
-Model: B-link BT4 (x5-Z8500)
-CPU: Intel Atom x5-Z8500 (Quad-Core)
-Graphics: Intel HD Graphics
-RAM: 4GB
-Storage: 64GB Solid State / Flash
-Operating System: Windows 10
-Network: RJ45 Gigabit Ethernet (1000M)
-I/O Ports: 4x USB 3.0, 1x HDMI, 1x VGA, 1x Audio Jack, 1x TF Slot
-Operating Environment: -10°C to 45°C (30%–90% Humidity)
-Dimensions: 120mm x 120mm x 22mm
