Description

Technical Product Overview:
This hardware unit allows for the connection of three HDMI input sources to a single HDMI output display. It utilizes the HDMI 1.4a standard to facilitate signal switching between connected devices. The device is a passive, low-power design that operates without an external power supply.

Key Technical Features:
-Input/Output Configuration: 3 x HDMI 1.4a Inputs; 1 x HDMI 1.4a Output
-Resolution Support: Supports 4K×2K and Full 3D formats
-Switching Method: Manual selection via integrated button or the included infrared (IR) remote control
-Audio Compatibility: Supports multi-channel digital audio, including Dolby TrueHD and DTS-HD Master Audio 7.1CH
-Standards Compliance: Fully compatible with HDMI 1.4a, CTS 1.4a, and DVI 1.0 specifications
-HDCP Functionality: Includes integrated HDCP repeater capability for content protection compliance
-Power Management: Bus-powered hardware; no external DC power source is required for standard operation

Technical Specifications:
-Interface: 3 × HDMI Type A Inputs / 1 × HDMI Type A Output
-Video Standard: HDMI 1.4a.
-Max Resolution: 3840 x 2160 (4K) at 30Hz.
-Data Rate: Supports up to 3.0Gbps per channel.
-Dimensions: Compact metal or ABS housing (check your specific unit for material)
-Included Components: * 1x 3-Way HDMI Switcher
-1x IR Remote Control
